HR012G

HR012G

Cordless Combination Hammer

40Vmax XGT BL AFT AWS AVT Cordless 28 mm (1-1/8″) Combination Hammer, SDS-PLUS, Quick Change Chuck

  • Overview:
    The HR012G is a cordless 28mm (1-1/8″) SDS-plus combination hammer powered by a 40Vmax XGT Li-Ion battery. This tool delivers an impact energy of 3.3 J, a no-load speed of 0 to 1,130 rpm, and an impact rate of 0 to 5,000 bpm. It remains compact and lightweight even when the dust collection system is attached.
    Anti-Vibration Technology (AVT), including a counterweight mechanism, a vibration-absorbing handle structure, and an anti-vibration grip, reduces vibration transmitted to the hands, minimizing user strain during continuous operation.
  • Electronic switch enables speed and impact rate selection for enhanced usability
  • The dust collection system DX17 uses the tool’s motor and fan for dust collection, resulting in a lighter, more compact design without compromising performance.
  • Active Feedback sensing Technology (AFT) turns the motor off if bit rotation is suddenly forced to stop
  • High water-resistance compatible with XPT
  • Auto-start Wireless System (AWS) enables control via Bluetooth for on-demand dust extraction.
  • Quick-change chuck for SDS-plus can be easily exchanged for Quick-change drill chuck
  • Three operation modes: Rotation only, Hammering with rotation, and Hammering only
  • Torque limiter stops rotation if the bit jams for operator safety and enhanced motor protection
  • Constant speed control automatically maintains rotation speed even under load
  • The variable speed trigger allows for speed adjustments based on the material or application.
  • Twin-LED job light with preglow and afterglow functions for better illumination.
Share On :
  • Blows per minute:

    0 – 5,000 minˉ¹

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • No load speed:

    0 – 1,130 minˉ¹

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Capacity:

    Concrete (w/ TCT bit): 28 mm (1-1/8″)

    Core bit: 68 mm (2-11/16″)

    Diamond core bit: 80 mm (3-1/8″)

    Steel: 13 mm (1/2″)

    Wood: 32 mm (1-1/4″)

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Shank type :

    Hammer: SDS-PLUS Shank

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Operation mode:

    3 modes

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Impact energy:

    3.3 J

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Vibration level:

    10.2 m/s² (EN62841-2-6, Mode: Hammer drilling into concrete), 9.1 m/s² (EN62841-2-6, Mode: Hammer drilling into concrete with DX18), 6.9 m/s² (EN62841-2-6, Mode: Chiselling)

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Uncertainty (K) for Vibration:

    1.8 m/s² (EN62841-2-6, Mode: Hammer drilling into concrete), 1.5 m/s² (EN62841-2-6, Mode: Hammer drilling into concrete with DX18), 1.5 m/s² (EN62841-2-6, Mode: Chiselling)

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Sound pressure level:

    96 dB(A) (EN62841-2-6), 98 dB(A) (EN62841-2-6, with DX18)

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Sound power level:

    104 dB(A) (EN62841-2-6), 106 dB(A) (EN62841-2-6, with DX18)

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Uncertainty (K) for Noise:

    3 dB(A) (EN62841-2-6), 3 dB(A) (EN62841-2-6, with DX18)

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Dimensions (L x W x H):

    419 x 104 x 223 mm (16-1/2 x 4-1/8 x 8-3/4″)

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Dimensions (Battery):

    BL4040/BL4040F

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Net weight:

    4.0 – 5.4 kg

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Net weight (Battery):

    BL4020 – BL4080F

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

  • Net weight (Attachment):

    w/o Side grip

    Lorem ipsum dummy

    Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.Lorem ipsum is a dummy text.

Standard Accessories:

  • HR012GZ: Tool (1), Grease vessel set (1), Depth gauge (1), Grip (1), Drill chuck 13mm (1), Carton box.
  • HR012GM201: Tool (1), Grease vessel set (1), Depth gauge (1), Grip (1), Drill chuck 13mm (1), Makpac, BL4040(2), DC40RA (1).
  • HR012GM202: Tool (1), Grease vessel set (1), Depth gauge (1), Grip (1), Drill chuck 13mm (1), Makpac, Sealing cap (5), DX18 dust collection system (1), BL4040(2), DC40RA (1).
